DTM320 MILL

Machine Specifications

 METRIC
Table working area550 x 160mm
Table travel X axis300mm
Cross travel Y axis140mm
Head travel Z axis300mm
Distance table to spindle nose:
min55mm
max355mm
Table tee slots:
number3
size12mm
spacing43mm
Axis feed rate0 – 1000mm/Min
Axis rapid rate1000mm/Min
Spindle taperR8
Spindle speed – infinitely variable0-3500rpm
Spindle motor.38kw
Axes motors80w
Axis screw diameter16mm
Machine dimensions:
length1250mm
width785mm
height1400mm
weight300kg
